Skid Steer Flail Mower

Description

Case Drain Required

The Baumalight FEB700 flail mower is a heavy duty and versatile agricultural tool designed for efficiently mowing and mulching a variety of vegetation, including grass, weeds, light brush, and small trees. The mower features a sturdy frame that is designed to withstand the rigors of demanding work environments, making it ideal for use in agricultural, commercial, and municipal applications. Its low-profile design allows for excellent forward visibility and eliminates “blind spots” as material nears or enters the machine. With a path width of 88 inches and a rotor width of 80 inches, this flail mower is capable of covering large areas quickly and efficiently. The specially designed back discharge feature allows material to flow evenly and smoothly through the machine resulting in unmatched capacity and performance.

The rotor is equipped with heavy-duty, free-swinging flail knives that are designed to effectively cut and shred vegetation while minimizing damage to the underlying soil. The FEB700 Flail mower comes with 42 blade clusters in a spiral pattern, which are mounted on a rotor shaft that measures 1.75 inches in diameter. The rotor diameter at the tips is 17.5 inches, and the rotor weight, including tools, is 253 lbs.

The FEB700 uses a standard universal skidsteer mounting plate making it easy to attach and remove from your vehicle and works well from 18-35 GPM and takes up to 4000 PSI. However, it does require a case drain to be installed for smooth operation. To maintain a steady, even mow height, the flail mower can be easily adjusted by lifting or lowering the skidsteer plate as the mower pivots on the roller bar. The unique floating skidsteer plate and independent linkage provide free movement and allows the mower to glide over uneven surfaces ensuring a uniform and consistently mowed finish in most types of terrain.

To ensure the longevity of the FEB700 Flail mower and reduce repair costs over time, a built-in relief system is installed to provide protection against overload or other damaging events. This system protection plays a critical role in safeguarding the machine from potential damage. Overall, the Baumalight FEB700 flail mower is a heavy build light industrial tool with a goal to give reliable performance, durability, and versatility for a variety of mowing and mulching applications.

Path Width 88″
Rotor Width 80″
Cutting Depth Level
Cutter style Flail Blades
No. of blade clusters 42
Rotor shaft size 1.75
Rotor diameter (tips) 17.5″
Rotor weight (with tools) 253 lbs
Hoses supplied Yes
Case drain required Yes
System Protection Built-in Relief system
GPM 18 – 35
PSI 2,000 – 4,000
Unit Weight 1091 lbs
